DescriptionGarage Door Operator – ProMatic BiSecur – NEW Series 4 (Head Only) The ProMatic garage door operators feature the same proven Hörmann technology as all Hörmann premium operators. This guarantees reliable function – at an attractive price. Some of the NEW series 4 operator features include: Energy-efficient LED lighting for bright, even garage illumination Low power consumption of less than 1 watt in stand-by mode Up to 40% faster door opening in comparison to ProMatic series 3 HCP interface to connect accessories or external SmartHome systems ProMatic Pull and push force: 600N Peak force: 750N Opening speed: max. 20 cm/s ¹ Door width: up to 5000 mm (max. 11.25 m² door surface) The ProMatic cannot be used on Hörmann LPU 67 sectional garage doors. 1) Depending on door type, door leaf weight and door size Downloads Installation Instructions Reviews Additional Technical InformationGarage door operator for domestic use – not suitable for commercial use! For dry areas only. Product Description: Door cycles (Open / Close) Per day / per hour 25 / 10 Doors with wicket door / timber doors Timber doors with max. 3.5m door width and 9m² door leaf surface Max. door width 5000mm Max. door leaf surface 11.25m² Operator Details: Motor 24 V DC gear drive Mains voltage 230 V – 240 V AC, 50 / 60 Hz Power input 0.2 kW Pull and push force 600 N Peak force 750 N Door travel speed ¹ max. 20 cm/s ¹ for travel in the OPEN direction max. 14 cm/s ¹ for travel in the CLOSE direction Standby < 1 watt Housing Plastic, galvanized steel base plate Temperature range -20°C to 60°C Protection category Only for dry rooms Control Electronics: Display LED Operation and programming Control buttons in the operator cover Impulse control Yes Adjustable power limit Yes Adjustable belt relief Yes Adjustable operator light / partial opening / ventilation position Yes Adjustable automatic timer 30 – 180 sec. Pre-set operator light 60 sec. High speed opening function Yes Equipment: Hand transmitter 868MHz 2 x 4-button hand transmitter HSE 4 BS Textured surface with plastic caps (black) Integrated receiver 868MHz Bi-directional 5-channel receiver BS LED lighting 10 LED Connection for photocell / closing edge safety device Yes Connection of external control elements Yes Connection for emergency battery Yes Quick release operated from the inside Yes Connecting lead with British 13amp 3-PIN plug Yes Anti-lift kit for break-in resistance Yes Universal installation bracket for up-and-over doors and sectional doors Yes Supplied with full instructions in English. Operator boom FS 10 (at additional cost): Self-supporting steel boom with polyester/polyamide toothed belt Maintenance-free toothed belt Plastic slide carriage and automatic belt tensioner 1-piece, completely pre-assembled Note: Installation of photocell is required if automatic timer is activated or impulse control without view of the door. 1) Depending on door type, door leaf weight and door size How it worksHow to video guide for the Promatic 4
