DescriptionFischer Chemical Anchor Injection Mortar Fischer injection mortar FIS VL 410 C. Includes – 1 cartridge 410 ml, 2 x FIS MR Plus. The solid injection mortar for standard applications in cracked concrete and masonry. The Fischer injection mortar FIS VL is a vinyl ester hybrid mortar with approval for fixing standard applications in cracked concrete and masonry. The FIS VL is processed with the approved system components Fischer threaded rod FIS A and Fischer internal-threaded anchor RG M I indoors and outside. The temperature resistance of the FIS VL injection mortar of -40 °C to 120 °C allows for a solid load level even when subjected to high temperature demands, thus providing great flexibility. Advantages The FIS VL is approved for use in cracked concrete and masonry, and achieves a high load-bearing capacity in these conditions The injection mortar, based on vinylester resin, allows for anchorings in water-filled drill holes (410 ml cartridges only), thus allowing for rapid progress The temperature resistance of the FIS VL injection mortar of -40 °C to 120 °C allows for a solid load level even when subjected to high temperature demands, thus providing great flexibility Downloads Load Table Safety Data Sheet Technical DataTechnical Data ETA-approval Yes Contents 1 cartridge 410 ml, 2 x FIS MR Plus GTIN (EAN-Code) 4048962269741 Reviews Application Applications Steelwork constructions Timber constructions Guard rails Façades Staircases Steel brackets Machines Masts Awnings Canopies Gates Consoles Pipelines Gratings Satellite antennas Building Materials Approved for anchorings in: Concrete C20/25 to C50/60, cracked Hollow blocks made from lightweight concrete Vertically perforated brick Perforated sand-lime brick Solid sand-lime brick Solid brick Rebar connections Aerated concrete Also suitable for: Concrete C12/15 Hollow blocks made from concrete Permission ETA-10/0352 ETA-15/0539, ETAG 001-5 DoP No. 0028 DoP No. 0028 DoP No. 0067 DoP No. 0067 DoP No. 0074 DoP No. 0074 DoP No. 0107 DoP No. 0107 GS 3.2/18-159-1-r1 21909_1 AssemblyFunctionality The FIS VL is a 2-component injection mortar based on vinyl ester Resin and hardener are stored in two separate chambers and are not mixed and activated until extrusion through the static mixer The mortar is extruded bubble free from the drill hole base The mortar bonds the entire surface of the anchor with the drill hole wall and seals the drill hole The 410 ml coaxial cartridges can be easily used with the fischer FIS AC dispenser Partially used cartridges can be reused by changing the static mixer
